Hot Stamping (Press Hardening) Automation
Solution introduction
Aotto is one of the world’s leading suppliers of complete, turn-key production solutions for manufacturing press vehicle parts and one of the true pioneers in the industry. Since 2000, we have provided 150+ hot stamping lines for customers globally, which has given us unique experience.
Structural display
Flow Direction - L type
①
Robots or crossbar manipulator are available for the destacking unit.
Trolleys or fixed tables are available for sheet transportation, and the direction of off-line can be parallel or perpendicular to the flow direction of the heating furnace.
Trolleys or fixed tables are available for sheet transportation, and the direction of off-line can be parallel or perpendicular to the flow direction of the heating furnace.
②
Two motion modes: Transfer and Feeder.
The loading direction is perpendicular to the logistics direction of the heating furnace.
Chain conveyor: Unloading on the left/right side.
The loading direction is perpendicular to the logistics direction of the heating furnace.
Chain conveyor: Unloading on the left/right side.
Flow Direction - linear type
① Marking: single or double side for mechanical marking or laser marking.
Gripper Option to select automatic tool changer.
Gripper Option to select automatic tool changer.
② Motion mode: Feeder.
Loading direction: parallel to the heating furnace flow direction.
Manipulator (both sides): Option to select automatic tool changer.
Loading direction: parallel to the heating furnace flow direction.
Manipulator (both sides): Option to select automatic tool changer.
Inter-press Hot Stamping Transfer
①Loading and unloading manipulator and tooling
②Automatic tooling changer
Safety Guard Unit
①Visual security system
②Machine guarding fence
③Safety locks
④Safety doors
⑤Roller shutter doors
Electrical & Software Units
①Thermal imaging system
②Safety management system for die area
③Quality traceability
④MES system
Case view
Hot Stamping Line with Roller-hearth Furnace
Annual stroke up to 1,450,000.Delivered 150+ lines globally.
Hot Stamping Line with Chamber Furnace
1. Independent temperature control；
2. Multi-temperature zone design；
3. The furnace cavity can be enabled/disabled according to the production capacity；
4. Individually disassembled for easy maintenance;
5. Free of circulating water for oven rack cooling.
Visual Die Protection and Quality Traceability
Track the temperature of blank for both pre-forming and post-forming, Monitor the forming process and raise alarm when:1. Misallignment of blanks;
2. Double-blank;
3. Formed parts not taken out, etc.
Automatic Racking Solution
Fully automated finished part racking with robots and vision system.
